Working voltage DC12V
Working current 150-200mA
Working frequency 13.56MHz
Exterior dimensions: width 86mm * height 86mm * thickness 23mm
The product weighs around 80g
Main color black
LED light color blue
Standby current ≤ 50mA
Power consumption 0.5W
Communication format Wiegand 26/34 (100 meters) is optional;
Card reading response time<350ms
The distance between the card reading and the IC card is 4-6cm, while the distance between the CPU card and the IC card is 3-4cm. The actual installation effect depends on the installation environment limitations
Supports CPU cards and IC cards
Working humidity 5% -95% (no condensation)
Working temperature -10 ℃~50 ℃
