Size 330mm x 230mm x 70mm
Weight 5.7kg
Working voltage 12V DC
Working current 2A
Main control chip 32-bit ARM Cortex-M4, clock frequency 168MHz, supports FPU (Floating Point Unit) and DSP instructions
512K FLASH and 192K SRAM memory.
Communication methods: TCP/IP standard Ethernet communication, HTTP protocol
Authentication methods support offline local mode and network authentication mode
Input 1 fire alarm input
The maximum offline record of card swiping is 60000
Maximum offline authorization capacity of 160000 pieces
Working environment Working temperature -15~60
Storage temperature -20~45
Network interface RJ45 Ethernet port
Other interfaces: 3-channel 485 interface
