Size: 165mm x 110mm x 30mm

Working voltage: 12vDC

Working current: 300mA.

Communication method: TCP/IP standard Ethernet communication. Maximum number of networking nodes: 254 devices per channel. There is no limit to the number of device nodes in the standard Ethernet star cascade mode. Card issuance volume: 16 million bit permissions combined with 65535 list permissions (download with name)

Card swiping records: 61260 records

Read and write time:<0.3 seconds

Reading distance:>50mm

Key input: 1 way. (Optoelectronic isolation protection)

Equipped with a set of relay outputs, it can be activated by swiping the card normally

It has one set of external green lights, one set of external red lights, and one set of external buzzer interfaces with one set of WG26 or WG34 signal inputs, which can be connected to an external reading head.
