Size: Single core 1400 * 160 (241) * 980mm

Size: Dual movement 1400 * 160 (322) * 980mm

Material: Stainless Steel SUS 304

Drive voltage: 24V

Backup power supply: supercapacitor (12V/3A)

Channel width: 600-1000MM (customizable)

Swing arm: 8mm thick acrylic

Traffic direction: one-way/two-way

Induction method: infrared radiation

Infrared: 5 pairs

Opening speed: 0.2 seconds to 0.5 seconds (adjustable)

Traffic speed: 30-35 people/minute (normally closed)

Operating environment: -20 ℃~70 ℃

Working voltage: AC220V+10%

Top cover thickness: 1.0mm

Body thickness: 0.8mm

Movement: Brushless speed gate movement with encoder, running smoothly and with low noise

Motor: 24V DC motor

Thread hole position: Knock off hole * 4

Communication interface: dry contact switch quantity, relay, fire interface

Access mode: Supports card swiping, facial recognition, QR code, fingerprint, etc

Safety functions: fire protection/anti pinch/anti-collision/anti tailgating/anti reverse intrusion, etc

Packaging cardboard box: 5-layer 5mm double pit cardboard box

Machine net weight: single core 50kg; dual core 61kg
