Dimensions: 1400 * 160 * 980mm

Road width: 600mm (customizable up to 900mm)

Chassis material: National standard 304 stainless steel

Board thickness: 1.5+1.2mm for the entire machine

Surface technology: Full machine drawing

Production process: fully computerized CNC laser cutting, fully computerized CNC bending

Swing arm material: high-quality acrylic board

Movement: Brushless Speed Pass Movement

Opening time: 0.2s

Traffic speed: 35 people/minute

Voltage: 220V 50HZ

Driving voltage: 24V

Power: 45W

Drive signal: 12v dry contact

Working voltage: DC24V

Supply voltage: 110V to 240V AC (wide power input voltage)

Power switch: leakage protection switch

Infrared logarithm: 6 pairs

Traffic direction: one-way/two-way

Equipment noise: ≤ 52db; door opening and closing ≤ 55db

Traffic speed: 35 people/minute in normally closed mode; Normal mode 60 people/minute

Movement lifespan: 5 million cycles

Operating temperature: -20 to 70 ° C

Storage temperature: -40 to 80 ° C

Relative humidity: 5% to 95% in non solidified state

Traffic indicator light: red/blue/green three color LED light
