Size: 1400 * 160 (300) * 980mm

Material: Stainless Steel SUS 304

Drive voltage: 24V

Backup power supply: supercapacitor (12V/3A)

Channel width: 550mm

Wings: Blue, Red/Transparent (optional)

Traffic direction: one-way/two-way

Induction method: infrared radiation

Infrared: 3 pairs

Opening speed: 0.2 seconds to 0.5 seconds (adjustable)

Traffic speed: 30-35 people/minute (normally closed)

Operating environment: -20 ℃~70 ℃

Working voltage: AC220V+10%

Top cover thickness: 1.0mm

Body thickness: 0.8mm

Movement: Wing brake movement

Motor: 24V DC motor

Thread hole position: Knock off hole * 4

Communication interface: dry contact switch quantity, relay, fire interface

Access mode: Supports card swiping, facial recognition, QR code, fingerprint, etc

Safety features: anti pinch/anti-collision/anti tailgating/anti reverse intrusion, etc

Packaging cardboard box: 5-layer 5mm double pit cardboard box

Net weight of machine: single core 42kg; dual core 53kg
