Size: 168 * 168 * 1050mm

Material: Stainless Steel SUS 304

Drive voltage: 24V

Backup power supply: supercapacitor (12V/3A)

Channel width: 600-1200mm (customizable)

Swing arm: 8mm thick acrylic

Traffic direction: one-way/two-way

Opening speed: 0.2 seconds to 0.5 seconds (adjustable)

Traffic speed: 30-35 people/minute (normally closed)

Operating environment: -20 ℃~70 ℃

Working voltage: AC220V+10%

Body thickness: 2.0mm

Movement: Swing Brake Brushless Anti collision Movement

Motor: 24V brushless motor

Communication interface: dry contact switch quantity, relay, fire interface

Access mode: Supports card swiping, facial recognition, QR code, fingerprint, etc

Safety functions: fire protection/anti pinch/anti-collision, etc

Packaging cardboard box: 5-layer 5mm double pit cardboard box

Net weight of machine: single core 34kg; dual core 40kg
