Appearance size 420 * 320 * 1100MM

Working power supply AC220V ± 10% DC24V

Adaptation pole length of 3.9 meters to 4.5 meters (including chassis+80mm)

Packaging volume 460 * 360 * 1120mm

Motor power 180W

Body color: black silver

Main and auxiliary pole specifications: 120 * 80/38 * 25 rubber strip

Working temperature -35 ℃~+80 ℃

Chassis material: Cold drawn steel 2.0mm thick high-temperature baked paint

Railing material 650 * 100mm louver rod/aluminum alloy

Remote control frequency 433 frequency band remote control distance 10 meters~50 range weight 70KG

Motor specifications: Wall mounted D07 brushless motor

DC24V brushless controller

The takeoff and landing speed can be adjusted within 3-5 seconds

Technical Introduction: High performance permanent magnet motor side installation method, wide body structure, motor power of 180W, input voltage of DC24V, rated current of 10A, motor speed of 1500R/MIN, working temperature and humidity range: temperature -35 ℃ to 80 ℃, humidity within 90%, landing gear speed of 2.5S/6S, suitable for up to 6 meters long four railings/advertising gate pole length of 5 meters, suitable for conventional commercial complexes or institutional units for lane entrance and exit applications
