Input voltage: 220V+10%/50HZ

Motor parameters: AC220V, 250W

Operating environment temperature: -25 ℃ to+80 ℃

Relative humidity: ≤ 90% without condensation

Sluice pole length: up to 4.5 meters in length

Lifting time: AC version 6S, variable frequency version with adjustable speed

Spring ratio: configuration with 6 long rods

Remote control distance: ≤ 30m

Input signal: Relay signal

The chassis is welded with high-quality cold-rolled steel plates with a thickness of 1.8mm, which is sturdy, durable, and has an external shape

Curved shape, rounded and soft.

After acid washing, phosphating, and electrostatic spraying, the chassis enters a high-temperature oven and is heated for 2 hours

Multiple surface treatment processes such as melting ensure that the chassis has extended protection in harsh outdoor environments

Rust time, UV resistance, and resistance to fading when exposed to sunlight.

The movement adopts a 250W power motor and bipolar deceleration. Controlled the motor during frequent use

The temperature rise prevents the motor from experiencing thermal protection and is less likely to burn out.

Using the most stable non constant speed operating mechanism, the gate rod can start slowly, run quickly, and stop slowly,

Eliminate the shaking caused by the gate during the landing process.

The spring group adopts a symmetrical combination design, which ensures more uniform force distribution and makes the brake lever more stable during the lifting and lowering process

Smooth out and have a longer lifespan.

Multiple control methods available for users to choose from, including external control box buttons for implementing barrier gates

Manual control for raising, lowering, and stopping, or remote control device can be selected to remotely operate the barrier gate

Get out of control.

Can be used in conjunction with vehicle detectors, enabling it to have "automatic pole drop" and "falling" functions when there is a vehicle

The functions of "automatic lifting of the pole with the vehicle" can enable the gate to have automatic closing and perfect anti smashing capabilities

Vehicle functions.

In addition to the universal interface, this system has added other protective devices such as infrared sensors, thereby

Make the system have functions such as anti smashing cars and people

It has a priority function to effectively improve the efficiency of vehicle traffic.

The end of the gate pole adopts a retractable landing pole, which can meet any installation situation with or without a safety island

Easy to use, convenient for on-site adjustment, convenient and practical.

At the bottom of the auxiliary pole, there is a pressure wave anti blocking rubber strip installed, which can be used in conjunction with pressure waves to achieve resistance reversal

Bounce function reduces the damage caused to people and vehicles due to misoperation.

According to the actual needs on site, our company can provide multiple configurations for you to choose from
