Exterior dimensions: 290 * 350 * 1120mm

Working temperature of the movement: -25'C~+85'C

Working temperature of the electrical control box: -20'C~+75'C

Power supply: 220V ± 10% 50/60Hz

Rated power: 200W Relative humidity: ≤ 90% Remote control distance: ≥ 30M

Net weight: 50KG

Highly integrated and integrated movement, the internal linkage structure of the movement adopts a hidden design, and the structure is exquisite.

The internal of the screw reducer adopts screw transmission, which has high transmission efficiency and large output torque.

The connecting rod structural components are formed by molds, with high processing accuracy and stability.

Servo motor drive, controllable speed, precise positioning, strong adaptability, smooth operation, and relatively fast motor acceleration and deceleration dynamics.

The servo mechanism is relatively self-locking, and the mechanism applies force through a motor to ensure that the rod cannot be manually lifted in the falling state. In the event of a power outage, the motor does not apply force, and the rod can be lifted, eliminating the need for clutch and hand cranking structures.

The motor and reducer are designed to be directly connected, with high transmission efficiency and strong stability.

The flange design of the reducer housing connection does not require internal structural processing, and the bearing position is precise.

Designed with multiple thin wires balanced by springs, it has a long lifespan and is not easily broken.

Adopting cast aluminum pole handle, the pole head can be quickly disassembled. Adopting cast aluminum buckle, the appearance is exquisite.
