Exterior dimensions: 290 * 352 * 1132mm

Working temperature of the movement: -25'C~+85'C

Working temperature of the electrical control box: -20'C~+75'C

Power supply: 220V ± 10% 50/60Hz

Rated power: 200W Relative humidity: ≤ 90% Remote control distance: ≥ 30M

Net weight: 40KG

The product advantage adopts an integrated movement and full mold production, greatly improving product stability and ensuring the operational accuracy of the barrier gate;

Adopting a turbine vortex rod transmission structure, the gate rod operates quickly and smoothly, effectively reducing gate rod vibration, reducing motor load, and extending the service life of the barrier gate;

24V DC brushless motor, with large output torque and small size, can achieve speed adjustment through the controller. When the falling and lifting rods are in place, it can achieve deceleration buffering, making the brake rod smoothly in place;

Automatically lift the pole during power outage, convenient and fast;

Rebound when encountering obstacles: If the brake lever encounters external obstruction during the falling process, it will automatically lift up, reducing damage caused by errors;

24-hour continuous operation of the motor without thermal protection;
