Exterior dimensions: 236 * 460 * 1100mm

Working temperature of the movement: -25'C~+85'C

Working temperature of the electrical control box: -20'C~+75'C

Power supply: 220V ± 10% 50/60Hz

Rated power: 150W Relative humidity: ≤ 90% Remote control distance: ≥ 30M

Net weight: 40KG

Power outage hand cranked motor bottom handwheel lifting rod, automatic reset upon power supply

Curved arm linkage mechanism structure, starting, falling, and stopping

Rebound upon encountering obstruction (only available with circular tooth limit device)

Infrared anti smashing (requires infrared anti smashing device)

Support ground sensing anti smashing and automatic pole drop when passing by (ground sensing device needs to be installed)

Control signals for opening and closing the parking lot system (required to be dry contact signals)

Traffic light interface, dry contact output (can connect traffic lights with current<10A)

Provide limit status signal to the parking lot system (output COM/NC) with delayed automatic pole dropping function (this function is disabled by default at the factory)
