Size:

Column: pole length 600mm, pole diameter 110mm

Shield: 12 inches

Screen body: 400mm * 148mm * 600mm

The system automatically supports a maximum of 512 x 64 dot arrays

Hardware supports simultaneous access to 2 standard units (64x32) of LED display screens, with a maximum of 8 LED standard display screens connected in series

The system supports setting up to 4 program contents

Each program content can have up to 16 display areas, and each display area can independently specify the display content, display mode, etc

Support left, right, up, down, and static display (automatically switches beyond the display area)

Surface mounted dual primary color 8-scan outdoor high brightness unit board identification rate: ≥ 99.8% during the day; Night time ≥ 99.5%

License plate capture rate: ≥ 99.9% during the day; Night time ≥ 99.8%

Adaptive car: 0-30 kilometers per hour

Output information: Vehicle feature image, license plate image, license plate number, color, type, transit time

Data interface mode: 10/100M Ethernet TCPIP

Image sensor: 1/2.8 "CMOS

Effective pixels: 5 million

Storage (built-in SD card, not standard): 100000 photos, 20000 license plates

Electronic Shutter: 1/1 to 1/10000 seconds, 22 levels

Best shooting range: 3-5 meters

Protection level: IP66

Working temperature: -25 ℃~70 ℃

Working humidity: ≤ 90%

Power supply voltage: DC 7-24V, ripple<200mV

Storage temperature: -50 ℃~120 ℃

Power consumption: 10W
