RF standard: Complies with ISO/IEC 14443 Type A/B

13.56MHz ± 7kHz

Card reading standard: "GA450-2013 General Technical Requirements for Desktop Resident ID Card Readers";

GA467-2004 Interface Technical Specification for Resident Identity Card Verification Security Control Module, ICAO 9303 Machine Readable Travel Documents - Part 1 Machine Readable Passport Fifth Edition.

Card type: Hong Kong and Macau Travel Permit (Hong Kong and Macau Travel Permit);

Mainland Travel Permit for Hong Kong and Macao Residents (Home Return Permit);

Taiwan Travel Permit (Taiwan Pass);

Taiwan Resident Travel Permit to Mainland China (Taiwan Compatriot Permit);

Resident ID card (second-generation card);

Residence permit for residents of Hong Kong, Macau, and Taiwan;

Permanent Resident Identity Card for Foreigners (Chinese Green Card);

Support customization of various documents;

Security module: Embedded ID verification system dedicated module (SAM) (optional accessory)

Operation time: less than 3 seconds (related to the card)

Working voltage: DC 12V ± 5%

Working current: Static current ≤ 200 mA, peak current ≤ 1500 mA

Communication interface: USB 2.1 high-speed interface

Environmental conditions: Operation: 0 ℃~50 ℃, 0-90% RH (no condensation);

Storage: -20 ℃~60 ℃, 0-95% RH (non condensing);

Net weight of card machine: about 350g
